PipeCaster  Pro

TM

SIPP (Sprayed-in-Place-Pipe lining) Injection casting system for in-house pipe rehabilitation
  • Cost-Effective

  • Plug and play

  • No Reinstatement

  • Ready to ship today

Two component, commercial Pipe Coating System for dispensing of polyurea, polyurethane & epoxy products. Premium components and a rugged construction make this machine a prime choice.
Digital, pre-programmed control unit for superior product application at even speeds. The applicator mounted speed control knob offers a wide variety of dispensing volumes to suit your product and application needs. Large volume reprogramming possible for larger pipe repair needs. International custom built types 110V and 220V available.


For Professional Use


Made In U.S.A.

Rentals Available! Contact us for details!

IPP Solutions, CIPP, Cured-In-Place-Pipe, Cured-In-Place-Pipe Lining, Epoxy Coating, Sewer Line Repair, Trenchless Pipe Lining, CIPP Lining, Cured-In-Place Pipe Rehabilitation, CIPP Equipment, Cured In Place Pipe Equipment, CIPP Pipe Lining, Sewer Line Lining, Trenchless Sewer Line Repair, SIPP, Spray-In-Place Pipeline (SIPP), Relining Sewer Pipes, Sewer Pipe Lining System, Sewer Pipe Coating, Pipe Liner, Pipe Relining, Sewer Pipe Lining Companies, Sewer Line Rehabilitation, Spray In Place Pipe, Spray In Place Pipe Lining Manufacturers, Spray In Place Pipe Lining Equipment, SIPP Equipment
SIPP Spraylining system, spray-in-place-pipe, sewer pipe coating equipment,
 Repair pipes up to 24"

Resin System

  • Removable stainless steel tanks with lids

  • Quick Connect stainless steel tank holders



  • Quick Connect fittings



  • Computer controlled resin pump system

  • Separate resin flow control

  • Wireless remote control



  • Powerful pneumatic resin spray head with static mixer for quality material output

  • Skids for variable pipe sizes

  • 100ft dual material hose with pneumatic tube attached

Air Compressor System

  • Ultra quiet & Oil free Air Compressor


  • 2 hp compressor motor


  • 6.40 CFM @ 40 psi


  • 5.30 CFM @ 90 psi


  • 10 gallon steel tank


  • Air pressure regulator


  • Tank pressure gauge


  • Working pressure gauge


  • Quick connect air fittings


  • Release valve for condense water


  • Air dryer


  • 100ft dual material hose with pneumatic tube attached

Cabinet

High Quality Sound proof Steel Cabinet with removable doors and locks



Swivel casters with stoppers



Dimensions without tanks:

• Depth: 30 inches

• Height: 31.5 inches

• Width: 20 inches



Dimensions with tanks:

Depth: 33 inches

• Height: 39.5 inches

• Width: 30 inches

Spray head

  • Pneumatic Sprayer

  • Stainless Steel

  • Light weight

  • Maintenance free

  • Disposable spray head

  • Easy to clean

  • Length overall 1 ¾”

  • Diameter overall 1 1/8”

  • Air connection 1/8”

  • Material connections ¼”

Compressor requirements:

  • 20 gallons, 4 cfm, 90 psi

  • Presents a Cost Effective solution compared to European products.

  • Ultra Quiet & Oil Free Air Compressor with sound proof cabinet

  • Made in the U.S.A. with a full warranty.

  • Built on a strong but lightweight aluminum frame.

  • Through direct application of the resin, no need to use liners.

  • Can be used though existing access points in the structure

  • Provides a lower initial price point.

  • ​Digital controls allow for mixing two components in different ratios

  • Supplies and parts are readily available.

  • Set on strong casters making it easy to transport.

  • With no liners, there is no need for any reinstatements

  • No need to create access points through structural alterations.

  • Requires much less maintenance and is more reliable.

  • Digitally controlled output volume dispenser for a variety of different pipe diameters.

  • Industry leading service on all equipment.

  • Can either be plugged in or used with the built-in battery

  • Application is easy and can be done quickly.

  • Services can be promptly restored to the property owner.

SIPP - Spray lining for commercial and residential high-rise buildings
02:22

SIPP - Spray lining for commercial and residential high-rise buildings

SIPP is an innovative pipe rehabilitation technique where a protective lining is sprayed directly onto the interior surfaces of existing pipes. This process restores the structural integrity of pipes, prevents leaks, and enhances flow capacity, all without the need to dig up and replace old piping systems. The SIPP method is ideal for a wide range of applications, including water mains, sewer lines, storm drains, and industrial pipelines. Property and maintenance managers overseeing hotels and high-rise buildings face significant challenges when it comes to maintaining and rehabilitating plumbing systems. Traditional methods of pipe rehabilitation can be costly, disruptive, and time-consuming. However, a groundbreaking solution has emerged in the form of the PipeCaster Pro Spray Lining System, offering a range of benefits for in-house pipe rehabilitation. PipeCasterTM Pro Spray Lining Benefits: 1. Minimized Disruption: The PipeCaster Pro system significantly reduces disruptions to daily operations. Unlike traditional methods, which often require extensive demolition, the PipeCaster Pro is minimally invasive, allowing businesses to continue their activities with minimal disturbance to staff and guests. 2. Cost-Effective: This system offers a cost-effective solution, reducing labor and material costs associated with traditional pipe replacement. Property and maintenance managers can achieve significant cost savings. 3. Sustainability: The PipeCaster Pro system is environmentally friendly. By rehabilitating existing pipes, it reduces the need for new materials, making it a sustainable option. This supports a commitment to environmental responsibility while achieving a practical goal. 4. Efficiency: The PipeCaster Pro Spray Lining System is known for its efficiency. It can be applied to various types of pipes, including those with multiple bends and configurations. The process is quick, allowing hotels and high-rises to resume regular operations sooner and enabling maintenance teams to work more efficiently. 5. Long-Lasting Solution: The PipeCaster Pro system provides a long-lasting solution for pipe rehabilitation. The applied lining is durable and corrosion-resistant, extending the life of the pipes and reducing the need for frequent repairs. This translates to long-term savings for property and maintenance managers. 6. Improved Water Quality: Aging pipes can contribute to water quality issues, such as discoloration or contamination. The PipeCaster Pro Spray Lining System not only rehabilitates the pipes but also improves water quality. It eliminates the risk of lead and other contaminants leaching into the water supply, ensuring safer and cleaner water for building occupants. 7. Minimal Labor and Time Investment: Traditional pipe replacement or rehabilitation can take weeks or months. In contrast, the PipeCaster Pro system typically requires significantly less time. This is essential for property and maintenance managers balancing ongoing operations with maintenance tasks.
PipeCaster Pro - for easy pipe rehabilitation
01:04
